Single Scan Line
1D
Brightness
1D Laser
IP65
Gun Shape
Industrial
| Description | Download |
|---|---|
| Honeywell Granit 1280i datasheet (Honeywell global) | Open Honeywell Granit 1280i datasheet on the maker's site (new tab) |
| Honeywell Granit 1280i product page (Honeywell Australia, Asia-Pacific) | Open Honeywell Granit 1280i product page on the maker's site (new tab) |
Honeywell lists these features for the Granit 1280i:
Industrial Grade Cable Option: Tested to withstand 300,000 90° bends at -30 °C and continues to communicate when 60lbs of force is applied. The industrial grade cable will stand up to your environment. Full Range Linear Depth of Field: Scan out to 54 feet (16.5m) on 100 mil retro-reflective labels, or as close as 3.5 in (8.9 cm) on 7.5 mil high density bar codes and everything in between. Remote MasterMind™ Scanning Management Software: Quick and convenient solution for IT administrators seeking to manage scanners within their network from a single remote location. Outstanding Scan Performance on Poor Quality and Damaged Bar Codes: Maintains productivity by providing a worry-free scanning solution that minimizes the need for error-prone manual data entry. Class-Leading Durability: The custom built IP65 rated housing is able to withstand 5,000 (1m) tumbles and survive 50 drops from 6.5 feet (2m) at -30 °C (-22 °F), reducing service costs and increasing device uptime. Optimized for Scanning-Intensive Industrial Applications: Provides aggressive bar code reading and unrivaled accuracy, along with enhanced scanner feedback, for use in extremely noisy environments.| DIMENSIONS | Dimensions |
13.3 x 7.5 x 19.5 cm 5.2 x 2.9 x 7.7 in |
| SCANNING | Skew | 65 |
| Decode Capability | 1D | |
| Pitch | 65 | |
| Scanning Range | Long Range (FR/LR) | |
| Print Contrast | 35% | |
| Scan Pattern | Single Scan Line | |
| Brightness | 0 - 70000 lux | |
| NETWORK | Bluetooth | No |
| HARDWARE | Host System Interface | RS-232 |
| Engine Type | 1D Laser | |
| Aimer Type | Laser | |
| Wireless | No | |
| ELECTRICAL | Standby Power | 0.75 W (150 mA at 5 V DC) |
| ENVIRONMENTAL | Storage Temperature Range |
- 40 - 158 °F - 40 - 70 °C |
| STANDARDS & APPROVALS | Tumble Specifications | 5,000 1 m (3.3 ft) tumbles |
| Drop Specifications | 50 2 m (6.5 ft) drops | |
| Protection Ratings | IP65 | |
| OTHERS | Form Factor | Gun Shape |
| Operating Power | 1.8 W | |
| Input Voltage | 4 - 5.5 V DC | |
| Operating Temperature | -30 °C to 50 °C (-22 °F to 122 °F); -30 °C needs the industrial-grade cable; up to 40 °C in presentation mode | |
| Power Connector Type | Corded |
