A 4-inch all-metal industrial label printer that Zebra built on its 105SLPlus: up to 305 mm/s (12 ips) at 203 dpi, with Gigabit Ethernet, USB, serial and Bluetooth LE built in.
Print width
104 mm (4.09 in.)
Speed
Up to 305 mm/s (12 ips) at 203 dpi; 254 mm/s (10 ips) at 300 dpi
Zebra ZT510 price in India: on written quotation. Share the model, quantity and city; we reply within one working day (Monday to Saturday, 9:30 AM to 6:30 PM).
Covered by the manufacturer's warranty. The warranty period, terms and conditions are as declared by Zebra.
The ZT510 is Zebra's 4-inch industrial printer built on its 105SLPlus, with Link-OS management added. Zebra aims it at buyers who want an industrial printer's metal build and speed without paying for extras: it has a backlit multi-line display with a keypad instead of a touch screen, and Gigabit Ethernet, USB, serial and Bluetooth LE as standard.
Metal build for dusty shop floors
Zebra gives the ZT510 an all-metal design on a metal frame, with sealed dome buttons that keep out dust, dirt and moisture. It weighs 22.7 kg, so plan a sturdy bench or stand.
Network-ready without an add-on card
Gigabit Ethernet, USB 2.0, RS-232 serial and Bluetooth LE are standard, with a static NFC tag for Print Touch pairing with Android phones. Zebra recommends Bluetooth LE for setup and light data, not for heavy print jobs.
Two open slots for later upgrades
Two communication slots take a dual-band 802.11ac Wi-Fi and Bluetooth card, a parallel card or a second Ethernet card; a USB host card and an IPv6 print server on the parallel port are also offered. Zebra lists the slot cards, cutter and peeler as field-installable.
Long labels and big rolls
It prints continuous labels up to 3810 mm long at 203 dpi (2540 mm at 300 dpi), takes media rolls up to 203 mm across on a 76 mm core and ribbons up to 450 m long, which Zebra matches 3:1 to the media roll.
Memory for graphics, fonts and formats
An 800 MHz Cortex A9 processor and 2 GB of flash (512 MB for your files) store graphics, fonts and label formats in the printer. It has 16 resident bitmap and two scalable ZPL fonts, with Unicode for multi-language printing.
Managed from one screen with Zebra's tools
Link-OS and Zebra DNA tools let you update firmware, change settings and watch status on-site or remotely; the printer's web page (Web View) and email alerts work over the network. It is ENERGY STAR qualified.
Used in
Manufacturing: product identification, packaging, receiving and put-away, and work-in-process labels
Transportation and logistics: order picking and packing, shipping and receiving, cross-docking and compliance labels
Warehouses (Zebra names manufacturing and warehouse environments for the ZT510)
For buyers in India
Using the ZT510 in India
These are the points buyers in India ask us about the ZT510. Mention the ones that apply to you when you request a quote.
Printing from older EPL software? Check before you order
Send us a sample of the label job your software prints today before you order. Zebra's ZT510 documents list ZPL and ZPL II with XML-enabled printing, and no EPL.
Keep it below 40 °C on the shop floor
Place the ZT510 away from ovens, sealers and direct sun. Zebra rates it for 5 °C to 40 °C in thermal transfer and 0 °C to 40 °C in direct thermal, at 20-85% humidity, non-condensing.
Adding Wi-Fi? Ask for the rest-of-world card
Ask for the rest-of-world version of the Wi-Fi and Bluetooth card; we confirm it in the quotation. Zebra's accessories guide lists the ZT510's dual-band 802.11ac card in North America, Japan and rest-of-world versions.
Specifications
Zebra ZT510 technical specifications
Zebra ZT510 specifications
General
Print methods
Thermal transfer and direct thermal
Construction
Metal frame; all-metal design with sealed dome buttons
User interface
Backlit multi-line graphic display with menu, keypad and user-programmable password protection
Processor
Cortex A9, 800 MHz
Flash
2 GB on-board (512 MB user available)
DRAM
32 MB user available
Standard features
Thin film printhead with E3 Element Energy Equalizer; dual media sensors (transmissive and reflective); auto calibration; printhead-cleaning early warning; real-time clock; advanced label counters; static NFC tag (Print Touch); ENERGY STAR qualified
Programming languages
ZPL and ZPL II; XML-enabled printing; ZBI 2.0 optional
Software
Link-OS and Zebra DNA tools (document design, device integration, device management, developer tools); Web View; Alert; Zebra Setup Utilities; ZebraDesigner Windows driver; Printer Profile Manager Enterprise; PrintSecure
Printing
Resolution
203 dpi/8 dots per mm standard; 300 dpi/12 dots per mm optional
Maximum print width
4.09 in./104 mm
Maximum print speed
12 ips/305 mm per second at 203 dpi; 10 ips/254 mm per second at 300 dpi
Maximum continuous print length
150 in./3810 mm (203 dpi); 100 in./2540 mm (300 dpi)
Maximum non-continuous print length
39 in./991 mm
Media registration tolerance
Vertical ±0.75 mm at 6 ips or slower, ±1.5 mm above 6 ips; horizontal ±1.5 mm
Barcode modulus (X) dimension
203 dpi: 4.9 to 49 mil (picket fence and ladder); 300 dpi: 3.3 to 33 mil picket fence, 3.9 to 39 mil ladder
Barcode ratios
2:1, 7:3, 5:2 and 3:1
Linear barcodes
Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC Case Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2- or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar, Planet Code
16 resident expandable ZPL II bitmap fonts and two resident scalable ZPL fonts; Asian and other international scalable and bitmapped fonts; Unicode for multi-language printing; IBM Code Page 850 and Code Pages 1250, 1252, 1253, 1254, 1255 with font 0
Media and ribbon
Media width (label and liner)
0.79 in./20 mm to 4.5 in./114 mm
Minimum label length
Tear-off 18 mm (0.7 in.); peel 13 mm (0.5 in.); rewind 6 mm (0.25 in.); cutter 38 mm (1.5 in.)
Media thickness (label and liner)
0.076 mm (0.003 in.) to 0.305 mm (0.012 in.); up to 0.23 mm (0.009 in.) with the cutter
Maximum media roll
8.0 in./203 mm outside diameter on a 3 in./76 mm core
Media types
Continuous, die-cut, notch, black-mark
Ribbon length
1476 ft/450 m
Ribbon width
2.00 in./51 mm to 4.33 in./110 mm (Zebra's user guide allows narrower ribbon, down to 20 mm, if it is wider than the media and tested with it)
Ribbon core and roll
1.0 in./25.4 mm inside diameter core; roll up to 3.2 in./81.3 mm outside diameter
Ribbon winding
Coated side out; optional ribbon spindle for ribbon coated on the inside
Connectivity
Standard
USB 2.0 full speed (12 Mbps); RS-232 serial (DB9F); internal Gigabit Ethernet (auto-switching); Bluetooth LE; static NFC tag (Print Touch)
Optional (two slots)
Dual-band 802.11ac Wi-Fi with Bluetooth card (top slot only); IEEE 1284 bidirectional parallel card; second wired Ethernet print server (bottom slot)
Other options
USB host port card; IPv6 external print server (needs the parallel card)
Keyboard display unit
ZKDU keyboard display unit for stand-alone printing
Physical and environment
Height
15.58 in./395.7 mm
Width
10.56 in./268.2 mm
Depth
20.17 in./512.3 mm
Weight
50 lb/22.7 kg
Operating temperature
Thermal transfer 5 °C to 40 °C (40 °F to 104 °F); direct thermal 0 °C to 40 °C (32 °F to 104 °F)
Operating humidity
20% to 85% non-condensing
Storage and transport
-30 °C to 60 °C (-22 °F to 140 °F); 20% to 85% non-condensing
Electrical
Auto-detecting universal supply with power-factor correction, covering 100-240 VAC, 50-60 Hz; ENERGY STAR qualified
Agency approvals
IEC 60950, EN 55022 Class B, EN 55024, EN 61000-3-2, EN 61000-3-3
Covered by the manufacturer's warranty. The warranty period, terms and conditions are as declared by Zebra.
Optional accessories
Dual-band 802.11ac Wi-Fi and Bluetooth card
Parallel port card
Internal Ethernet (IPv4) print server card
IPv6 external print server (needs the parallel port card)
USB host port card
Cutter with catch tray
Rewinder (rewinds a full roll on a 3 in. core, or peels and rewinds the liner)
Ribbon spindle for ribbon coated on the inside
203 dpi and 300 dpi replacement printheads
ZKDU keyboard display unit
ZBI 2.0 programming option
Ask for a Wi-Fi card, cutter or rewinder in the same quotation; Zebra lists the slot cards, cutter and peeler as field-installable, so they can also be added later.
Specifications from Zebra's ZT510 spec sheet (Zebra Asia Pacific web edition, 03/18/2019), ZT510 technical specifications (Zebra global English file, updated 01/2021) and ZT510 user guide (Zebra English edition, 2026/10/14); where the documents differ we print only the values they share and confirm the rest in the quotation, last checked 20 October 2026.
Makers can change specifications without notice.
About our product information
More detail
More about the Zebra ZT510
Zebra built the ZT510 on its 105SLPlus printer, adding Link-OS management; Zebra describes it as built for 24/7 operation.
Print width: 4.09 inch / 104 mm. Maximum print speed: up to 12 ips/305 mm per second at 203 dpi (10 ips/254 mm at 300 dpi). Print resolution: 203 dpi resolution, 300 dpi resolution (optional). Construction: all metal.
Communication methods: Standard: USB, serial, Gigabit Ethernet, Bluetooth LE. Optional: parallel, 802.11ac Wi-Fi with Bluetooth, USB host, IPv6 (external dongle on the parallel port).
What the Zebra ZT510 is used for: Work-in-Process, Product Identification Labels, Shipping Labels, Receiving Labels, Packaging Labels, Compliance Labels.
Heavy-duty 4-inch labels at 203 or 300 dpi on a wired network
Non-stop 4-inch lines and 600 dpi micro labels
4-inch industrial labels in most plants and warehouses
Light-industrial labelling in a small space
Exploring for a different use?
If your job differs from what the ZT510 is built for, these Zebra models may fit it better:
Buyers who need 600 dpi for small part labels, or a colour touch display, often look at the
Zebra ZT610 (203, 300 or 600 dpi, up to 14 ips, Gigabit Ethernet).
Buyers who want an optional UHF RFID encoder on a 4-inch printer often look at the
Zebra ZT411 (optional UHF RFID encoder and on-metal tag kit).
Buyers who print 6-inch carton, pallet or drum labels, often look at the
Zebra ZT421 (up to 168 mm print width).
Buyers who print standard 4-inch labels in a smaller space often look at the
Zebra ZT231 (light-industrial, up to 12 ips).
The ZT510 price depends on the resolution you choose (203 or 300 dpi), the options you add and the quantity. We can quote the labels and ribbon with it. We do not publish prices: share the model, quantity and city, and we send a written quotation with current pricing and
delivery time, replying within one working day.
Is the Zebra ZT510 still sold?
Yes. Zebra Asia Pacific lists the ZT510 among its current industrial printers, and its ZT510 support page carries no discontinuation notice; we checked both on 20 October 2026.
Can we add Wi-Fi, a cutter or a rewinder after we buy it?
Yes. Zebra lists the slot cards, cutter and peeler as field-installable. The dual-band 802.11ac Wi-Fi and Bluetooth card fits the top slot; a parallel card or a second Ethernet card can go in the other. A USB host card is also offered.
Will our current label formats print on the ZT510?
If your software sends ZPL, yes: the ZT510 runs ZPL and ZPL II with XML-enabled printing. Zebra's ZT510 documents do not list EPL, so send us one label your software prints today and we test it before you order.
What labels and ribbons does it take?
Labels and liner 20 mm to 114 mm wide and 0.076 mm to 0.305 mm thick, on rolls up to 203 mm across on a 76 mm core. Ribbons are up to 450 m long on a 25.4 mm core, 51 mm to 110 mm wide, coated side out. It also prints direct thermal without a ribbon.
ZT510 or ZT610: which should we choose?
Both print 104 mm wide and have Gigabit Ethernet built in. The ZT610 is faster (14 ips against 12 ips at 203 dpi), offers a 600 dpi printhead and has a 4.3-inch colour touch display. The ZT510 prints at 203 or 300 dpi and has a backlit display with a keypad.
Can Allmark install the ZT510 and connect it to our software?
Yes. We install the ZT510 at your site, connect it so your ERP, warehouse or billing software prints to it (our own warehouse management system included) and train the people who use it. Tell us the software when you ask for a quote, and we include the setup in the quotation.
Get a written ZT510 quote with labels and setup
Send your label size, how many labels you print a day and the software you print from; we reply with a written quotation.
